Specification

CW62100E

CW62155E

CW62140E

CW62125

CW62140

CW62160

CW62180/1

Swing overbet

mm(in)

1000(40)

1250(50)

1400(56)

1250(50)

1400(56)

1600(64)

1800(72)

Swing overgap

mm(in)

1250(50)

1500(60)

1650(66)

1750(870)

1930(77)

2110(84)

Swing over carriage

mm(in)

650(26)

900(36)

980(38)

900(36)

1100(44)

1280(51)

1480(59)

Maximum turning length

mm(in)

1500-16000(60-640)

1500-16000(60-640)

Maximum weight of workpiece batween centers

kg

6000、8000

8000、10000

Width of the bed

mm(in)

755(33)

970(39)

Spindle noses No.

ISO

A2-15

A2-15

Diameter of spindle front bearing

mm(in)

200(8)

200(8)、220(8.8)

Diameter of spindle hole

mm(in)

130(5.2)  100(4)

130(5.2)、100(4)

Taper hole of spindle

Metric No.140

Metric No.140

Number of spindle speeds

（Manual operating)

Range of spindle speeds

r/min

3.15-315   2.5-250(2-200)

3.15-315   2.5-250(2-200)

Main motor power

kw

AC22

AC22

Rapid travelling speed of motor power

kw

1.5

1.5

Section of tool shank

mm(in)

45×45(1.8×1.8)

45×45(1.8×1.8)

Swivel angle of tool post

±90°

±90°

Travel of transvers tool post

mm(in)

200(8)

200(8)

Travel of longitudinal tool post

200(8)

400(16)

200(8)

400(16)

travel of cross slide

mm(in)

520(21)

695(27)

720(28)

880(35)

Rapid travelling speed of　longitudinal tool post

mm/min

935

935

Rapid travelling speed of transverse

mm/min

1870

1870

Rapid travelling speed of longitudinal

mm/min

3740

3740

Metric threads number and range

mm

45、1-120

45、1-120

Inch threads number and range

T.P.I.

42、30-1/4

42、30-1/4

Modul threads number and range

mm

46、0.5-60

46、0.5-60

Diameter pitch threads number and range

D.P.

48、60-0.5

48、60-0.5

Longitudinal number and range of feeds

m/rev

97、0.064-12

97、0.064-12

Transverse number and range of feeds

m/rev

97、0.032-6

97、0.032-6

Longitudinal tool post number and range of feeds

m/rev

97、0.016-3

97、0.016-3

Diameter of tailstock quill

mm(in)

160(6.4)

160(6.4) 200(8)

Taper hole of tailstock quill

Metric No.80、Morse No.6

Metric No.80、Morse No.6

Travel of tailstock quill

mm(in)

300(12)

300(12)

Weight of the lathe with 3m b.c.

kg

10800

11500

12300

11200

12200

13200

14200

Additional weight par 1m b.c.

kg

1200

1400

Machine overall dimension(length×width×height)(3m)

mm

6100×1900×2000

6100×2000×2100

6100
