Max turning diameter

mm

800

1000

1250

1600

2000

Table diameter

mm

720

900

1010

1400

1800

Max height of workpiece

dm

8

8

10/14

10/14/16

12.5/16/20

Max weight of workpiece

t

2

3

5

5/8

8/12

Max cutting force of rail head

kn

20

20

20

25

25

Max cutting force of slide head

kn

15

15

20

20

20

Max torque of table

kn.m

10

12.5

17.5

25

32

Range of table speeds(16 steps)

r/min

10-315

8-250

63-200

5-160

25-125

Swivel of rail head

±30°

±30°

±30°

±30°

±30°

Range of feed rates(12 steps)

mm/min

0.8-86

0.8-86

0.8-86

0.8-86

0.8-86

Horizontal travel of rail head

mm

570

670

700

915

1150

Ram travel of rail head

mm

650

650

650

800

800

Ram horizontal travel of side head

mm

500

500

500

500

630

Vertical travel of side head

mm

810

810

980

980

1180

Rapid traverse of tool heads

mm/min

1800

1800

1800

1800

1800

Size of tool bar section

mm

30x40

30x40

30x40

30x40

30x40

Power of main motor

kw

AC-22

AC-22

AC-22

AC-30

AC-37

Over dimensions

mm

2060x2620x2730

2167x2200x3313

2300x2300x3300

2630x2670x3870

3210x4030x4200
