Table size

mm

1270×320

1120×260

Table travel

mm

780×300×380

600×270×300

Number/Width/Distance of T-slot

5-14-70

3-14-63

Distance between spindle nose and table surface

mm

150-500

100-400

Distance between spindle axis and column surface

mm

150-550

100-650

Spindle travel

mm

127

127

Spindle taper(V/H)

mm

ISO40

ISO40

Spindle speed range

rpm

70-3620(V)60-1350(H)

65-4660（V）/38-1310（H）

Spindle motor power

kw

3.7(V)2.2(H)

2.2

Overall dimension

mm

1720×1520×2225

1710×1480×2100

Machine weight

kg

1650

1350
