Standard accessories:
Draw bar
Tool box and tools
Oil collecting plate
Auto lubricate pump
Coolant pump
Table guard
Working lamp
Optional accessories:
Digital readout
Power feed
Collet chuck and collets
Clamping kits
Machine vise
Inverter milling head
Variable speed milling head
Air power draw bar
Model | Unit | X7125 | X7130 | ||||
Table size | mm | 254x1270 | 254x1370 | 305x1370 | 305x1500 | ||
Table longitudinal travel | mm | 760 | 860 | 880 | 1000 | ||
Tabel cross travel | mm | 535 | 535 | 510 | 510 | ||
Milling head vertical travel | mm | 405 | 405 | 405 | 405 | ||
Distance from spindle to table | mm | 150-600 | |||||
Milling | Motor power | HP | 3 | 3 | 5 | 5 | |
Spindle taper | R8 | R8 | ISO40 | ISO40 | |||
Quill travel | mm | 127 | |||||
Spindle speed | Standard:16steps | rpm | 50HZ:65-4500 60HZ:80-5440 | ||||
Optional:variable | rom | 65-4200 | 60-3750 | ||||
Quill power feed | mm/rev | 0.04/0.08/0.15mm/rev | |||||
Package | one machine/package | mm | 1800x1500x2400 | 1850x1500x2400 | |||
two machine/package | mm | 2200x1500x2400 | 2250x1500x2400 | ||||
G.W. | one machine | kg | 1900 | 1900 | 2000 | 2050 | |
two machine | kg | 3900 | 3900 | 4000 | 4100 | ||
