Distance between centers

700mm

Swing over bed

250mm

Swing over cross slide

165mm

Taper of spindle bore

MT4

Spindle bore

26mm

Number of spindle speeds

6/variable speed

Range of spindle speeds

125-2000/50-2000rpm

Range of cross feeds

0.02 -0.28mm /r

Range of longitudinal feeds

0.07 -0.40mm /r

Range of inch threads

8-56T.P.I

Range of metric threads

0.2 -3.5mm

Top slide travel

50mm

Cross slide travel

140mm

Tailstock quill travel

80mm

Taper of tailstock quill

MT2

Motor

0.75/1.1KW

Packing size

1400 × 700 × 680mm

Net weight

210kg / 230kg

Mill & Drill Specifications

Taper of spindle bore

MT2

Spindle stroke

50mm

Spindle speed

50-2250rpm

Max.distance spindle to table

280mm

Max.distance spindle to columm

170mm

Motor

500W

Packing size

1270/1520 × 670 × 930mm

Net weight

180kg / 195kg
