Distance between centers

700mm

Swing over bed

280mm

Swing over cross slide

165mm

Taper of spindle bore

MT4

Width of bed

180mm

Spindle bore

26mm

Number of spindle speeds

6/variable

Range of spindle speeds

500-2000rpm

Range of longitudinal feeds

0.07 -0.20mm /r

Range of inch threads

8-56T.P.I

Range of metric threads

0.4 -3.5mm

Top slide travel

50mm

Travel of cross slidel

140mm

Tailstock quill travel

70mm

Taper of tailstock quill

MT2

Motor

1.1KW

Standard Accessories

Taper of spindle bore

MT2

Spindle stroke

50mm

Spindle speed

50-2250rpm

Max.distance spindle to table

375mm

Max.distance spindle to columm

185mm

Motor

600W

Packing size

1400 × 780 × 1070mm

Net weight

230kg / 250kg
