CW6263E

CW6280E

CW62100E

CW62120E

CW6263

CW6280(A)

CW62100(A)

CW62120(A)

Capacity

Max swing over bed

mm

630

800

1000

1200

630

800

1000

1200

Max swing over gap

830

1000

1200

1400

Max swing over cross slide

mm

350

485

685

800

345

480

680

680

Center distance

mm

750,1250,1750,2750,3750,4700,5700,8000,10000,12000

850,1350,1850,2850,4850,5850,7850,9850,11850

Max swing over gap

mm

830

1000

1200

1400

---

Valid length of gap

mm

230

---

Bed width

mm

550

600

Headstock

Spindle hole

mm

Φ105 or Φ130(CW6280E above)

Φ105 or Φ130(CW6280 above)

Spindle nose

C-11 or D-11

---

Spindle taper

1:20 Φ120(Φ140 CW6280E above)

Φ120 1:20(Φ140 CW6280 above)

Spindle speeds(Number)

rpm

14-750 18steps

7.5-1000

5.5-730

Gear box-threads&feeds

Metric threads range(kinds)

mm

1-240(54kinds)

1-240(52kinds)

Inch threads range(kinds)

28-1 inch(36kinds)

1-14(26kinds)

Moudle threads range(kinds)

0.5-60DP(27kinds)

0.5-120(53kinds)

Diametral threads range(kinds)

30-1 t.p.i(27kinds)

1-28t.p.i(24kinds)

Longitudinal feeds range(kinds)

mm/r

0.05-22.8(72kinds)

0.1-24.3

Cross feed range(kinds)

mm/r

0.015-7.6(72kinds)

0.05-12.15

Rapid feed:long/cross

m/min

6/2

4/2

Leadscrew size:Dia/Pitch

mm

T48/12

---

Carriage

Cross slide travel

mm

420

370

430

Compound rest travel

mm

200

200(A model for 170)

Size of tool shank

mm

32x32

32x32

Tailstock

Spindle diameter

mm

Φ100

Φ120

Φ100

Φ120

Spindle taper

MORSE#6

MORSE#6

Spindle travel

mm

240

240

Motor

Main drive motor

kw

11

11/15

Coolant pump motor

kw

0.09

---

Rapid feed motor

kw

0.18

1.1
