Main parameters

CWA6285

CWA62100

Swing over bed

mm(in)

850(34)

1030(41)

Swing over gap

mm(in)

1150(46)

1350(54)

Swing over carriage

mm(in)

520(21)

720(28)

Maximum turning length

mm(in)

1500-16000(60-640)

Maximum weight of workpiece batween centers

kg

4000

Width of the bed

mm(in)

600(24)

Spindle noses No.

ISO

A2-11

Diameter of spindle front bearing

mm(in)

160(6.4)

Diameter of spindle hole

mm(in)

100(4)

Taper hole of spindle

Metric No.120

Number of spindle speeds

(Manual operating)

Range of spindle speeds

r/min

5-630

Main motor power

kw

AC15

AC18.5

Rapid travelling speed of motor power

kw

1.1

Section of tool shank

mm(in)

32×32(1.3×1.3)

Swivel angle of tool post

±90°

Travel of tool post

mm(in)

250(10)

Travel of cross slide

mm(in)

600(24)

Rapid travelling speed of tool post

mm/min

900

Rapid travelling speed of transverse

mm/min

1800

Rapid travelling speed of longitudinal

mm/min

3640

Metric threads number and range

mm

56、1-120

Inch threads number and range

T.P.I.

56、30-1/4″

Modul threads number and range

mm

56、0.5-60

Diameter pitch threads number and range

D.P.

56、60-0.5

Longitudinal number and range of feeds

m/rev

64、0.08-9.6

Transverse number and range of feeds

m/rev

64、0.04-4.8

Longitudinal tool post number and range of feeds

m/rev

64、0.02-2.4

Diameter of tailstock quill

mm(in)

120(4.8)″

Taper hole of tailstock quill

Morse No.6

Travel of tailstock quill

mm(in)

250(10)″

Weight of the lathe with 3m b.c.

kg

5300

5800

Additional weight par 1m b.c.

kg

1000

Machine overall dimension(length×width×height)(3m)

mm

5150×1500×1500

5150×1600×1600
