Table size

mm

1120×260

1120×260

1120×260

Table travel

mm

600×270

600×270

600×300

Spindle taper

ISO40

ISO40

ISO40

Distance from spindle nose to table surface

mm

100-480

100-480

100-480

Max. end milling width

mm

125

125

125

Max. vertical milling dia.

mm

25

25

25

Spindle speed range

rpm

45-1660

45-1660

45-1660

Swivel angle of swivel head

360°

360°

360°

Overall dimension

mm

1655×1500×1730

1655×1500×1730

1655×1500×1730

Spindle motor power

kw

2.2

2.2

2.2

Machine weight

kg

1480

1400

1300
