Model | Unit | Z5125A | Z5132A | Z5140A | Z5150A | ZB5163B | ZB5180 |
Max drilling diameter | mm | 25 | 32 | 40 | 50 | 63 | 80 |
Max feeding resistance | N | 9000 | 10000 | 16000 | 16000 | 30000 | 30000 |
Max torque of main shaft | N.m | 160 | 250 | 350 | 400 | 800 | 800 |
Main motor power | kw | 2.2 | (2.2)3 | 3 | 3 | 5.5 | 7.5 |
Morse taper of main spindle | Morse | No.3 | No.4 | No.4 | N0.5 | N0.5 | N0.6 |
Distance from center of main shaft to guide surface | mm | 280 | 280 | 335 | 335 | 375 | 375 |
Travel of main shaft box | mm | 210 | 210 | 200 | 200 | 250 | 250 |
Travel of main shaft | mm | 200 | 200 | 250 | 250 | 250 | 250 |
Steps of main shaft rotational speed | 9 | 12 | 12 | 12 | 9 | 9 | |
Range of main shaft rotation speed | rev/min | 50-2000 | 45-2000 | 31.5-1400 | 40-1800 | 40-570(9) | 40-570(9) |
Feeding quantity of main shaft per rev | mm/rev | 0.056-1.8 | 0.056-1.8 | 0.056-1.8 | 0.056-1.8 | 0.1-0.78(6) | 0.1-0.78(6) |
Distance from the end of main shaft to bench surface | mm | ≤730 | ≤730 | ≤780 | ≤780 | ≤800(1250) | ≤800(1250) |
Travel of table | mm | 300 | 300 | 300 | 300 | 300 | 300 |
Working area of bench | mm | 400×550 | 400×550 | 480×560 | 480×560 | 550x650 | 550x650 |
Cooling pump power | kw | 0.09 | 0.09 | 0.09 | 0.09 | 0.09 | 0.09 |
Flow of cooling pump | L/min | 25 | 25 | 25 | 25 | 25 | 25 |
Overall dimensions(LxWxH) | mm | 1100×700×2120 | 1100×700×2120 | 1195×800×2550 | 1200×800×2550 | 965x1452x2787 | 965x1452x2787 |
Net weight | kg | 960 | 1000 | 1300 | 1350 | 1900 | 1900 |
