G4228 Double Column Horizontal Bandsaw, mainly used for cutting all kinds of metal materials and non-metallic materials, to meet the user processing of the Φ280mm following various materials sawing, cuttingmachinery industry indispensable equipment.
The GB4265 horizontal band sawing machine is mainly used for cutting all kinds of metal materials, non-metallic materials, can meet the customers of the the roundwood following Φ650mm size and 650 × 650 mmLumber sawing processing, large and medium-sized mechanical processing enterprisesindispensable cuttingequipment.
The sawing cutting all kinds of metal materials, including a variety of shaped steel, round steel. Band saw blade speed sawing, sawing speed can be stepless speed within the allowable range. Narrow kerf, high efficiency, energy and materials. The material used for large and medium-sized mechanical processing enterprises.
Model | Unit | G4228 | GB4250A | GB4265A | GB4280 | |
Cutting capacity | round | mm | Φ280 | Φ500 | Φ650 | Φ800 |
square | mm | 280x200 | 550x500 | 650x650 | 800x800 | |
Blade(WxTxL) | mm | 25x0.95x3150 | 41x1.3x5800 | 54x1.6x7100 | 41x1.3x6400 | |
Blade speed | m/min | 27,40,54,68,80 | 18-90 | 15-75 | 22-73 | |
Motor | main motor | kw | 2.2 | 5.5 | 5.5 | 7.5 |
oil pump | kw | 0.37 | 1.5 | 0.75 | 3.75 | |
coolant pump | kw | 0.04 | 0.25 | 0.25 | 0.25 | |
Hydraulic system pressure | Mpa | 2.2 | 4 | 4 | 4.8 | |
Table height | mm | 575 | 560 | 560 | 580 | |
Overall dimension | mm | 1628x1169x1393 | 1590x3028x1870 | 1525x3110x2038 | 4045x1460x2670 | |
Weight | kg | 580 | 2500 | 3000 | 7000 |
