Rectangular table guideways with high stability
Hardened and ground table surface
Automatic feeds on X.Y axes,motorized lifting and lowering of table on Z axis.
Model |
Units |
XW6032A |
XW6032B |
|
Table size |
mm |
1320×320 |
1320×320 |
|
Table travel |
mm |
800(750)×300 |
1000×300（manual） |
|
Number/Width/Distance of T-slot |
mm |
5-14-63 |
5-14-63 |
|
Spindle taper |
ISO50 |
ISO50 |
|
|
Distance from spindle axis to table surface |
mm |
0-400 |
0-400 |
|
Distance between spindle axis and boom |
mm |
175 |
175 |
|
Spindle speed range |
rpm |
58-1800 |
58-1800 |
|
Spindle motor power |
kW |
4 |
4 |
|
Overall dimension |
mm |
2070×1900×1850 |
2070×2020×1850 |
|
Machine weight |
kg |
2100 |
2200 |
