Rectangular table guideways with high stability
Hardened and ground table surface
Automatic feeds on X,Y axis,motorized lifting and falling of table on Z axis.
Headstock swivels ±45°
Model |
Unit |
X6036B |
X6036A/X6136A |
|
Spindle taper |
ISO50(H) |
ISO50(H) |
|
|
Distance from spindle to table |
mm |
0-400 |
0-400 |
|
Spindle speeds |
r.p.m |
60-1800 |
60-1800 |
|
Table size |
mm |
1250x360 |
1250x360 |
|
Table travel(Horizontal/Cross/Vertical) |
mm |
1000/320/400 |
600/320/400 |
|
Feeding range of longitudinal ;cross travel |
mm/min |
22-555(8 steps) |
22-555(8 steps) |
|
X,Y-axis rapid feed speed |
mm/min |
1080 |
1080 |
|
Z-axis rapid feed speed |
mm/min |
590 |
590 |
|
Z-axis motor power |
kw |
1.1 |
1.1 |
|
Max weight of workpiece |
kg |
400 |
400 |
|
T-slot number/width/distance |
mm |
3/18/80 |
3/18/80 |
|
Milling head moving(vertical) |
Rectangular rail |
Dovetail rail |
|
|
Cross slide way |
Rectangular rail |
Rectangular rail |
|
|
Longitudinal slide way |
Dovetail rail |
Dovetail rail |
|
|
Horse power for main motor |
kw |
4 |
4 |
|
Coolant pump power |
w/L |
90/25 |
90/25 |
|
X,Y axis driving motor |
w |
750 |
750 |
|
Overall dimension |
mm |
2220x1790x1880 |
1850x1790x1880 |
|
Packing size(one/double sets) |
mm |
1800x1900x2250 |
1800x1900x2250 |
|
N.W/G.W |
kg |
2200/2300 |
2100/2200 |
