Precision ground and supersonic frequency hardened bed ways.It features with high accuracy and well wear-resisting.
The spindle is supported with precision roller bearing.
Safety magnetic switch or lock key switch.
Model |
HD250 |
|
Max. swing over bed |
Φ250mm |
|
Max. swing over cross slide |
Φ140mm |
|
Distance between centers |
400mm/550mm/750mm |
|
Width of bed |
135mm |
|
Spindle bore |
Φ20mm |
|
Taper of spindle bore |
M.T.#3 |
|
Range of spindle speeds |
125-2000rpm |
|
Taper of tailstock quill |
M.T.#2 |
|
Metric threads can be cut |
0.4-3mm |
|
Inch threads can be cut |
10-44 T.P.I |
|
Range of longitudinal feeds |
0.1-0.2mm/rev |
|
Max. travel of cross slide |
110mm |
|
Max. travel of top slide |
70mm |
|
Max. travel of tailstock quill |
65mm |
|
Motor power |
550w |
|
Packing size |
1045/1155/1355mm×560mm×565mm |
|
N.W |
105/109/119kg |
|
G.W |
145/149/159kg |
|
Foot stands (L×W×H) |
500mm×300mm×750mm |
|
Foot stands (N.W) |
44kg |
|
Foot stands (G.W) |
48kg |
