Max width to be ground

mm

165

220

165

220

Max length to be ground

mm

470

470

470

520

Max height to be ground

mm

350

Table size

mm

155x460

210x450

150x460

200x520

Permanent magnetic chuck size(optional)

mm

150x400

200x400

150x400

200x450

Max longitudinal travel

mm

500

500

500

570

Max cross travel

mm

185

240

200

250

Max distance from spindle center to table surface

mm

450

Feed of vertical handwheel

per rev.

mm

1

2

per div.

mm

0.005

Grinding wheel size(ODxWxID)

mm

200x13x31.75

200x20x31.75

Spindle speed

r/min

3450(60HZ),2850(50HZ)

Power of spindle head

kw

Standard 1.5(build in spindle:1.1kw)

Max load capacity(include permanent magnetic chuck)

kg

97

128

110

140

Machine weight

kg

790

920

1000

1120

Machine opperance size(LxWxH)

mm

1330x1090x1680

1330x1150x1680

1360x1350x1710

1450x1390x1770

Package dimension(LxWxH)

mm

1153x1373x1920

1153x1413x1950

1670x1560x1930

1670x1700x1980

Package size(dismantle table)(LxWxH)

mm

1340x1120x1930

1400x1120x1980

1670x1120x1930

1670x1120x1980
