Working Surface of Table

mm

255×510(10"×20")

255×610(10"×20")

300×600(12"×24")

400×800(16"×32")

400×1000(16"×40")

Max. Table Travel

mm

575

675

660

920

1120

Max. Cross Travel

mm

280

280

370

450

450

Distance Between Table Surface and Spindle Center

mm

535

535

520

580

580

Max. Table Load

kgs

300

300

420

700

700

T-Slot（Number×Width)

mm

1×14

1×14

1×14

3×14

3×14

Table Speed

m/min

5～25

5～25

5～25

5～25

5～25

Crossfeed Handwheel

1 grad

mm

0.02

0.02

0.02

0.02

0.02

1 rev

5

5

5

5

5

Automatic Crossfeed of Saddle

mm

0.5～12

0.5～12

0.5～12

0.5～12

0.5～12

Power Cross Feed

50Hz

mm

790

790

790

790

790

60Hz

950

950

950

950

950

Grinding Wheel Dimensions

mm

200×25×32/31.75

200×25×32/31.75

355×40×127

355×40×127

355×40×127

Spindle Speed

50Hz

rpm

2850

2850

1450

1450

1450

60Hz

3420

3420

1740

1740

1740

Vertical Handwheel

1 grad

mm

0.01

0.01

0.01/0.01/0.001

0.01/0.01/0.001

0.01/0.01/0.001

1 rev

2

2

2/2/0.5

2/2/0.5

2/2/0.5

Automatic Down Feed Rate

mm

—/—/0.002~0.2

—/—/0.002~0.2

—/—/0.005~0.025

—/—/0.005~0.025

—/—/0.005~0.025

Power Head Increment

mm

—/380/—

—/380/—

—/380/230

—/380/230

—/380/230

Spindle Motor

kw

2.2

2.2

4

5.5

5.5

Vertical Motor

w

—/90/—

—/90/—

—/90/90

—/90/90

—/90/90

Hydraulic Motor

kw

1.5

1.5

1.5

2.2

2.2

Dust Collection Motor

w

550

550

550

550

550

Coolant Motor

w

90

90

90

90

90

Crossfeed Motor

w

60

60

90

90

90

Floor Space

mm

1900×2300

1900×2400

2600×2500

3600×2600

3600×2600

Packing Dimensions

mm

1960×156-×2140

2020×1610×2135

2080×1870×2195

2720×2155×2195

2920×2155×2195

Net Weight

kgs

1655/1680

1700/1730

1800/1810/1910

2800/2810/2850

2900/2910/2950

Gross Weight

kgs

1905/1930

1950/1980

2100/2100/2210

3100/3110/3150

3200/3210/3250
