Working Surface of Table

mm

500×1000(20"×40")

500×1500(20"×60")

600×1500(24"×60")

600×2000(24"×80")

Max. Table Travel

mm

1140

1600

1600

2230

Max. Cross Travel

mm

540

570

660

660

Distance Between Table Surface and Spindle Center

mm

590

590

600

600

Max. Table Load

kgs

700

700

800

1500

T-Slot（Number×Width)

mm

3×16

3×16

3×16

3×16

Table Speed

m/min

5～25

5～25

5～25

7～25

Crossfeed Handwheel

1 grad

mm

0.02

0.02

0.02

0.02

1 rev

5

5

5

5

Automatic Crossfeed of Saddle

mm

0.5～12

0.5～12

0.5～12

0.5～12

Power Cross Feed

50Hz

mm

1250

1250

1250

1250

60Hz

1500

1500

1500

1500

Grinding Wheel Dimensions

mm

355×40×127

355×40×127

355×50×127

355×50×127

Spindle Speed

50Hz

rpm

1450

1450

1450

1450

60Hz

1740

1740

1740

1740

Vertical Handwheel

1 grad

mm

0.002

0.002

0.002

0.002

1 rev

0.5

0.5

0.5

0.5

Automatic Down Feed Rate

mm

0.005~0.04

0.005~0.04

0.005~0.04

0.005~0.04

Power Head Increment

mm

230

230

230

230

Spindle Motor

kw

7.5

7.5

7.5

7.5

Vertical Motor

w

370

370

370

370

Hydraulic Motor

kw

2.2

2.2

5.5

5.5

Dust Collection Motor

w

550

550

550

550

Coolant Motor

w

90

90

90

90

Crossfeed Motor

w

370

370

370

370

Floor Space

mm

4445×2200

5810×2445

5810×2445

6200×2700

Packing Dimensions

mm

3400×2265×2250

4000×2285×2250

4000×2260×2250

4000×2260×2250

Net Weight

kgs

5000

6000

6250

8500

Gross Weight

kgs

6000

7000

7250

9700
