Drilling capacity

20mm

32mm

40mm

45mm

Face milling capacity

63mm

63mm

80mm

80mm

End milling capacity

20mm

20mm

32mm

32mm

Distance from spindle nose to table

435mm;439mm

450mm;440mm;450mm

450mm;440mm;450mm

450mm;440mm;450mm

Min.distance from spindle axis to column

181.5mm;197.5mm

203.5mm;272.5mm;260mm

203.5mm;272.5mm;260mm

203.5mm;272.5mm;260mm

Spindle travel

85mm

130mm

130mm

130mm

Spindle taper

M.T.3 or R8

M.T.3 or R8

M.T.4 or R8

M.T.4 or R8

Step of spindle speed

12;6

12;6;6

12;6;6

12;6;6

Range of spindle speed 50Hz

100-2200 r.p.m
95-1420 r.p.m

80-2080 r.p.m
80-1250 r.p.m
80-1250 r.p.m

80-2080 r.p.m
80-1250 r.p.m
80-1250 r.p.m

80-2080 r.p.m
80-1250 r.p.m
80-1250 r.p.m

60Hz

120-2640 r.p.m
115-1700 r.p.m

100-2500 r.p.m
95-1500 r.p.m
95-1500 r.p.m

100-2500 r.p.m
95-1500 r.p.m
95-1500 r.p.m

100-2500 r.p.m
95-1500 r.p.m
95-1500 r.p.m

Swivel angleof headstock (horizontally)

360°; 360°/±90°

360°; 360°/±90°/90°

360°; 360°/±90°/90°

360°; 360°/±90°/90°

Table size

520×160mm

800×240mm

800×240mm

800×240mm

Forward and backward travel of table

140mm

175mm

175mm

175mm

Left and right travel of table

290mm

500mm

500mm

500mm

Motor Power

0.55KW
0.37KW

0.75KW
0.75KW(1HP)
0.75KW(1HP)

1.1KW
1.1KW(1.5HP)
1.1KW(1.5HP)

1.5KW
1.5KW(2HP)
1.5KW(2HP)

Voltage/frequency

As customer's requirement

Net weight/gross weight

130kg/190kg
130kg/190kg

280kg/330kg
315kg/365kg
320kg/370kg

283kg/333kg
318kg/368kg
323kg/373kg

285kg/335kg
320kg/370kg
325kg/375kg

Packing size

620×750×1000mm
680×750×1000mm

1020×820×1160mm
770×880×1160mm
770×880×1160mm

1020×820×1160mm
770×880×1160mm
770×880×1160mm

1020×820×1160mm
770×880×1160mm
770×880×1160mm

Loading amount

48pcs/20＇container
48pcs/20＇container

28pcs/20＇container
36pcs/20＇container
36pcs/20＇container

28pcs/20＇container
36pcs/20＇container
36pcs/20＇container

28pcs/20＇container
36pcs/20＇container
36pcs/20＇container
